Description

Specifications:

  • Case pressure-relief grommet (Topside on liguid-fillable models, Backside on dry models).
  • AISI 316 Stainless Steel Case & Bayonet Ring (standard).
  • AISI 316 Stainless Socket & Element.
  • Black-anodised aluminium pointer (Micrometer adjustable is standard on 4” & 6” dial sizes).
  • Laminated Safety Glass Lens.
  • Dry, Filled, or VibraGauge® option.
  • White Painted Aluminum Dial, Black-printed figures.

Accuracy:

  • 0.5%  (Up to 10,000 psi).
  • 1.0%  (15,000 psi).
  • 1.5%  (Over 15,000 psi).

Additional Information:

Bop Glycerin Filled Gauge (Series 40S, 40SV, 41S, 41SV, 60S, 60SV) – Datasheet.
